P0047 - Turbocharger/Supercharger Boost Control A Circuit Low

Miguel Rodriguez
Miguel Rodriguez
4 min read

Review by: Miguel Rodriguez
Error Codes Maintenance

The P0047 diagnostic trouble code indicates a low voltage issue in the circuit controlling the boost pressure from the turbocharger or supercharger. This problem can lead to various performance issues and potential engine damage if left unresolved.

I. Introduction

The boost control system plays a vital role in regulating the air pressure supplied by the turbocharger or supercharger, ensuring efficient engine operation. When the powertrain control module (PCM) detects a low voltage signal from the boost control circuit, it triggers the P0047 code as a warning sign of a potential issue.

II. Understanding the Code

A. Definition and Meaning

The P0047 code, also known as "Turbocharger/Supercharger Boost Control A Circuit Low," signifies a problem with the circuit responsible for controlling the boost pressure generated by the forced induction system. This code is specific to vehicles equipped with either a turbocharger or a supercharger, which are air compressors designed to increase the engine's power output.

B. Causes

Several factors can contribute to the P0047 code being set, including:

Potential CausesDescription
Faulty Boost Pressure SensorProvides incorrect readings to the PCM
Wiring IssuesShorts, opens, or damaged wiring harnesses
Failed Turbo/SuperchargerMechanical issues affecting boost control
Defective Control ComponentsBoost control solenoid or VGT actuator failure
PCM FailureRare cases of PCM malfunction

III. Symptoms and Effects

A. Common Symptoms

When the P0047 code is present, drivers may experience:

  • Check engine light illumination

  • Poor engine performance and acceleration

  • Detonation or knocking noise from the engine

B. Potential Consequences

Ignoring the P0047 code can lead to:

  • Continued operation with low boost

  • Possible engine damage from excessive boost (overboost)

  • Increased emissions and reduced fuel efficiency

IV. Diagnosis Process

The diagnosis process typically involves:

  1. Scanning for codes and freeze frame data

  2. Inspecting wiring and connectors

  3. Testing components:

    • Boost pressure sensor

    • Boost control solenoid or VGT actuator

    • Checking for boost leaks or mechanical issues

V. Repair Procedures

After identifying the root cause, repair procedures may include:

A. Replacing Faulty Components

Replacing any defective or failed parts, such as:

  • Boost pressure sensor

  • Boost control solenoid

  • VGT actuator

  • Turbocharger/supercharger

B. Clearing Codes and Verifying Repair

  • Clearing diagnostic trouble codes

  • Test driving and monitoring boost control operation

  • Ensuring the check engine light remains off

VI. Importance of Proper Diagnosis and Repair

Addressing the P0047 code promptly is crucial for:

  • Maintaining optimal engine performance

  • Preventing engine damage

  • Emissions compliance

  • Fuel efficiency

  • Diagnostic trouble code clearance

VII. Conclusion

The P0047 code indicates a low voltage condition in the turbocharger or supercharger boost control circuit, which can lead to various performance issues and potential engine damage. Prompt and accurate diagnosis, followed by appropriate repair procedures, is essential to maintain optimal engine performance, emissions compliance, and prevent further complications.

FAQs

What is the purpose of a turbocharger or supercharger?

A turbocharger or supercharger is an air compressor that increases the amount of air entering the engine's cylinders, resulting in more power output.

How does the boost control system work?

The boost control system regulates the amount of boost pressure supplied by the turbocharger or supercharger through components like the boost control solenoid or variable geometry turbo (VGT) actuator, which are controlled by the powertrain control module (PCM).

What are the common symptoms of the P0047 code?

Common symptoms include the check engine light illumination, poor engine performance and acceleration, and potential detonation or knocking noises from the engine.

Can a wiring issue cause the P0047 code?

Yes, wiring issues such as shorts, opens, or damaged wiring harnesses in the boost control circuit can trigger the P0047 code.

Is it safe to continue driving with the P0047 code?

It is generally not recommended to continue driving for an extended period with the P0047 code active, as it can lead to potential engine damage or increased emissions.

How is the boost pressure sensor tested during diagnosis?

The boost pressure sensor is typically tested by checking its voltage output and resistance values against the manufacturer's specifications, as well as inspecting for any physical damage or corrosion.

What is the role of the boost control solenoid or VGT actuator?

The boost control solenoid or VGT actuator is responsible for regulating the amount of boost pressure supplied by the turbocharger or supercharger based on the PCM's commands.

Can a failed turbocharger or supercharger cause the P0047 code?

Yes, mechanical issues with the turbocharger or supercharger itself, such as internal oil leaks or bearing failures, can affect the boost control system and trigger the P0047 code.

Is it necessary to replace the entire turbocharger or supercharger if the P0047 code is present?

Not necessarily. The repair procedure may involve replacing specific components like the boost pressure sensor, control solenoid, or actuator, depending on the root cause identified during diagnosis.

After repairing the issue, it is essential to clear the diagnostic trouble codes, perform a test drive, and monitor the boost control operation to ensure the check engine light remains off and the system is functioning correctly.
